Five essentials for choosing the right energy system for battery test applications

Disruptive Change: From Combustion Engines to E-Motors

2018 Wolf Julia 1290124 1024x768

Julia Wolf (M.A.) Heinzinger Electronic

The major trend of electromobility is currently the biggest driver in the automotive industry. It is presenting OEMs and suppliers with tremendous challenges and permanently changing the rules of play in the automotive sector. Suddenly, the combustion engine is no longer the most important core area of expertise, but instead it is energy stores, power electronics, e-motors or even entire e-axles that are in demand. The winners and losers of this boom of tomorrow are being decided in the development departments of today.

The industry is working on new solutions to make our mobility eco-friendly and economical with resources. High costs, short ranges and long charging times have in the past been reasons why car buyers preferred combustion engines over electromobility. So car manufacturers, suppliers and service providers are working flat-out to move electromobility forward. The e-motor, and especially the battery, form the focus of attention, since they determine the range and driving behavior.

Development of voltages and power for electromobility

With the progress of electromobility, the demands for test equipment are changing. 48 Volt are already standard, voltages among 1,000 and higher gain further recognition. Previously we talked about power in the area of a few kilowatts, now more than 100 kW is necessary – in some instances there is the necessity of megawatts.

Conventional power supplies quickly reach their limits, in regard to connect power parallel to meet the required currents at all. The keyword for this solution is “flexible output”. According to the most recent status, this is the opportunity to build your system flexible and to expand it at a later time – cost-conscious with long-term security of investment.

But voltages and current on their own do not compose a battery tester or simulator. A number of further attributes should be considered when searching for the best fitting test system for your application:

  1. Security of investment through enhancement options
  2. Flexibility for different applications through the combination of any different output channels
  3. Realistic behaviour with high dynamic by compensation of current steps or changes
  4. Safety for test object, power supply and user
  5. Sustainability for a reliable system

If these criteria were taken into account, companies are on the safe side when choosing the components for their test benches.

  1. Security of investment through enhancement options

The already described changes in the demands of voltages and power in the automotive sector are showing, how important it is to build the system future-oriented, well prepared for future requirements. The option to upgrade your existing system at a future time with additional output channels or the possibility to connect them, should be offered. The option to connect or cascading further channels do not only offer flexibility (see on next point) but also security of the investment in the long-term. But of prime importance for every test house should be the ability to use the same hardware for battery tests and for battery simulation, simply by switching the software.

  • Flexibility for different applications through the combination of any different output channels

Point one and two are closely linked together: For the validation of prototypes, preliminary series and constantly changing products or subsystems, a high level of flexibility is essential. High quality technics and modern test bench concepts, which enable practical and realistic test with highest accuracy, are the crucial components. The possibility to use the several outputs as single or as multi-channel-system with serial or parallel connection, allows the option to build various current/voltage ranges and offers the best application security, especially for future requirements. The knowledge, that you are able to select, whether a system should rather deliver high current or high voltage up to 1200V, gives a feeling of satisfaction. A very essential point concerning the paralleling of output channels needs to be addressed carefully. It is essential, that a real Master-/Slave operation of the power supply itself is implemented. If the paralleling of different channels or even power units is attempted by an overall automation system, the desired high dynamic behavior may be significantly influenced. The reason being that nonspecific systems are not able to guarantee the necessary precise harmonization of current or power sharing.

If you pay attention to these options while choosing your power supply, you will get a system, which is able to meet different demands – whether it is for validation, quality control or end-of-Line testing.

  • Realistic behaviour with high dynamic by compensation of current steps or changes

It is here that the wheat is separated from the chaff of the manufacturers of battery tester and battery simulators. To test a battery to the limit of its capacity, it is important, that the system is working precise enough, to adjust current rapidly. Minimum and maximum setting values have to be configurable for the application of battery tests. To get valid and reproducible data during battery simulation, the rule is, that decreasing the voltage in small amounts, will result in more realistic simulation of the behavior of the battery. Minimal voltage-overshoots are also a sign for a high level of control of the system and an important aspect in regard to the security of the connected test object, because in the worst case a big voltage-overshoot could destroy it.

  • Safety for test object, power supply and user
Bild2 Overshoot 1024x768
Bild1 Adjust 1024x769
Phase for Adjust

Avoiding of uncontrolled charging and discharging currents

To make sure, that a battery is evaluated correctly and the state of charge of the connected memory will not be changed, e.g. the “currentless connection” of batteries is an important parameter. This approach is protecting the battery from damages, because it secures that both sides of the protection have the same voltage potential.

When a battery is connected to the DC controller, any uncontrolled charging or discharging currents from the battery must therefore be avoided. The battery voltage should be measured via a sensing input at the consumer before the battery is connected. Based on this measurement, the internal control circuit (which is equipped with a decoupling capacitor) is regulated to the voltage potential of the battery connected as a consumer. Only then the output voltage can be connected via the DC output contactor at the power unit output.

5. Safety through voltage target values

For the safety of the connected batteries, the maximum charging voltage should never be exceeded during charging and the minimum discharging voltage should never be fallen short of during discharging. To safeguard these requirements, the internal control of the power unit shall automatically switch to a voltage control type when the set and specified voltage target value is reached. The voltage set must be kept constant and the current lowered accordingly, protecting the battery connected as the load.

To protect the battery, the set values should be continuously monitored for their permissibility by the units’ internal control. When the set values entered are not permissible, they shall be ignored or reduced until no damage can occur to the consumer. The unit shall give a warning message, to prohibit the battery from discharging.

The subject of safety is one that cannot be skimmed over with e-motors and inverters. If a fault occurs in feedback mode, for example, and the system shuts down or if the output relays open, the interim circuit and the connections on the test object can still be live and this represents a danger for the operator and/or the test object itself.

In the case of a breakdown of the test unit, there are very high short-circuit currents, through high test voltages they increase again. Therefore special focus has to be set on the safety of the system and the peripheral equipment. To bring both into a secure operating state in case of an incident, these security measures are essential. Rapid discharge switches and freewheel systems take care of a save test environment and minimize the risks.

  • Sustainability for a reliable system

Electromobility and prevention of resources belong together. Not only for financial reasons but also from the sight of sustainability, it should be self-evident to work resource-saving. With the power of a few hundred kilowatt the energy consumption, the degree of efficiency and the ability to recover energy into the grid, are essential marks of a battery simulator. To keep the loss as low as possible, it should be possible to let the energy circulate between two test units via dual-channel operation (“energy balancing”). In opposition to the use of a single systems, only the losses of the test unit have to be taken from the grid. This approach offers the major advantage that tests with high power demands could be made even with low grid connection capacity.

Julia Wolf (M.A.)
Marketing Manager

Further notes


Heinzinger Werndl Alfred 682x1024

What do you think sets your company apart from your competitors?

Apart from our highest flexibility in the reaction on the requirements that are needed, the know-how of almost six decades is an advantage that cannot easily be topped. From the technical side of our test bench power supplies, we can say that there is no compatible solution on the market that can reach such a dynamic behavior of the output in battery test cycles.

In your opinion what key trends or developments do you see emerging in the next five years

For us the most emerging market is the e-mobility market, later on combined with smart grid applications. This will lead to a worldwide re-evaluation of existing structures in energy supply and create further opportunities in business – at the same time this will be good for our planet.

Managing Director

Alfred Werndl
